BMTS Series
Green Hydraulic
BMTS Series
Standard export carton/plywood case
YES
ISO9001 CE
1 set
Product Description
Ultra-short compact structure, suitable for narrow installation space
Low starting pressure, smooth rotation without crawling or shaking
Advanced wear compensation design, keeping high efficiency for long service life
Heavy-duty double bearings, strong load capacity and impact resistance
High-pressure resistant sealing system, adaptable to harsh working conditions
Bidirectional rotation, stable output torque
100% interchangeable with Danfoss OMTS series, direct replacement
Cost-effective and reliable for mass matching and after-sales replacement
Specifications
Structure: Short-body disc distribution geroler orbit hydraulic motor
Displacement range: 80–400 cc/rev
Max continuous working pressure: 210 bar (3045 PSI)
Max intermittent peak pressure: 250 bar (3625 PSI)
Rated speed range: 50–800 rpm
Rotation mode: Bi-directional reversible
Bearing configuration: Heavy-duty double rolling bearings for high radial & axial load
Standard seal material: NBR nitrile rubber; FKM fluorine rubber optional for high-temperature environment
Housing material: Cast iron, shock-resistant and wear-resistant
Core design: Built-in automatic wear compensation group for lasting volumetric efficiency
Mounting: Standard flange, multiple spline & flat key shaft options
Applicable medium: Standard mineral hydraulic oil
Operating oil temperature: -20℃ ~ +80℃
Applications
Construction machinery: Mini excavators, road rollers, compact road sweepers, small drill rigs
Agricultural equipment: Harvesters, fertilizer spreaders, hay cutters, farm wheel drive assemblies
Sanitation machinery: Street sweepers, snow blowers, waste compactors, cleaning vehicle wheel drives
Forestry machines: Wood splitters, log grapples, small wood chippers
Compact material handling: Mini conveyors, small hydraulic winches, turntable drive units
Other narrow-space mobile hydraulic equipment requiring low-speed high-torque output
Factory&FAQ
BMTS Series Orbit Motor are typically packaged securely to prevent damage during transit. The packaging includes:
Protective Wrapping: To safeguard the pump from environmental damage.
Custom Crates: For larger, heavier pumps, ensuring safe handling.
Documentation: Includes installation, maintenance instructions, and warranty details.
Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.
1. What is the BMTS Series Orbit Motor ?
BMTS Series Orbit Motor is a short compact low-speed high-torque geroler hydraulic motor with disc flow distribution and automatic wear compensation. It adopts a shorter housing design to fit limited installation space, equipped with heavy-duty double bearings to bear large radial and axial loads. It runs smoothly at low speed with stable efficiency, fully interchangeable with Danfoss OMTS series, widely matched for compact mobile hydraulic machinery.
Ultra-short compact body design, perfect for equipment with limited mounting space
Disc distribution plus automatic wear compensation, maintaining high volumetric efficiency for long service life
Heavy-duty double rolling bearings, strong resistance to radial, axial loads and impact
Low startup pressure, smooth low-speed rotation without crawling or vibration
Cast iron housing with high-pressure resistant seals, reliable under harsh working conditions
Bidirectional rotation with multiple shaft and flange choices for flexible installation
Full interchangeability with Danfoss OMTS series for direct plug-and-play replacement
Stable performance at competitive cost, ideal for mass OEM matching and aftermarket replacement
3. What is the working pressure range of BMTS Series Orbit Motor ?
Max continuous working pressure: 210 bar (3045 PSI)
Max intermittent peak pressure: 250 bar (3625 PSI)
4. Can BMTS Series Orbit Motor replace other brands?
Yes, BMTS orbit motor can directly replace many imported brand orbit motors.
It is fully interchangeable with Danfoss OMTS series with identical mounting dimensions, displacement and interface structure, plug-and-play without modifying equipment.
It also matches most domestic equivalent short-body BMT orbit motors for aftermarket replacement.
We provide customizable spline shafts, flat key shafts and special port threads to fit different original brand standards.
Its upgraded wear compensation and double bearing structure offer better load capacity and longer service life than many original motors.
Please confirm displacement, flange size, shaft type and pressure parameters before replacement for perfect matching.
6. What is the typical speed range of BMTS Series Orbit Motor ?
The typical operating speed range of BMTS Series Orbit Motor is 50 rpm to 800 rpm.
It delivers steady, jitter-free low-speed performance starting from 50 rpm without crawling.
800 rpm is the maximum rated speed under standard matched hydraulic flow.
Actual output speed can be adjusted flexibly by changing input oil flow.
This wide speed band suits both low-speed heavy-load operation and high-speed light-duty work.
7. Do you provide OEM or customized services?
Complete OEM and customized services are available for BMTS Series orbit motors.
OEM service includes custom customer logos, personalized nameplates and neutral export packaging.
Customizable items: spline shafts, flat key shafts, lengthened special shafts and different oil port thread specifications.
Seal upgrade option: replace standard NBR seals with FKM fluorine rubber for high-temperature working conditions.
Custom flange sizes and auxiliary valve assemblies can be produced according to customer technical drawings.
Small trial orders are supported, and bulk orders can enjoy favorable wholesale prices.
8. How can I get a quotation quickly
Please provide the following details:
Model or displacement
Working pressure
Speed
Quantity
We will reply within 12 hours with a competitive quotation.
BMTS Series Orbit Motor are manufactured in compliance with international standards, ensuring high performance and reliability:
ISO 9001: Certified for quality management systems.
CE Certification: Ensures compliance with European safety, health, and environmental protection standards.
RoHS Compliance: Ensures the pump does not contain hazardous materials.
Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
