BK2
Green Hydraulic
BK2
Standard export carton/plywood case
YES
ISO9001 CE
1 set
Product Description
Automatic compensation disc distribution design, anti-wear, long service life, stable efficiency under fluctuating pressure
Low startup torque, smooth forward & reverse rotation, wide adjustable speed range
Reinforced output bearing, withstand heavy radial and axial loads, suitable for direct wheel drive
High pressure resistance up to 21MPa continuous working pressure, peak pressure 31MPa for short overload
Complete specification lineup: 65–475cc displacement, multiple spline/flat key shafts, SAE standard mounting flanges
Compact body, easy installation; support series & parallel connection in hydraulic circuits
Low noise vibration, reliable sealing structure, strong anti-leak performance
Specifications
Displacement: 65 / 80 / 100 / 160 / 200 / 250 / 315 / 400 / 475 cc/rev
Continuous working pressure: 20.5–21 MPa (205–210 bar)
Intermittent pressure: 26–31 MPa (260–310 bar)
Max peak pressure: 31 MPa (310 bar)
Rated speed range: 230–865 RPM
Output torque: 150–665 N·m
Mounting flange: Standard SAE 2-hole flange, custom flanges available
Output shaft options: Straight key, involute spline, tapered spline
Recommended hydraulic oil: Anti-wear hydraulic oil, viscosity 37–73 cSt
Operating temperature: -20℃ ~ +80℃
Interchangeable: Direct replacement for Eaton Char-Lynn 2000 series
Certifications: CE, ISO9001
Custom service: OEM, ODM, matched wet disc brake optional
Applications
Farm tractors, rotary tillers, hay balers, fertilizer spreaders, harvesters, irrigation rotating drives
Small marine auxiliary drives, material handling conveyors, wheel drive units, mini drilling rigs
Factory&FAQ
BK2 Orbit Motor are typically packaged securely to prevent damage during transit. The packaging includes:
Protective Wrapping: To safeguard the pump from environmental damage.
Custom Crates: For larger, heavier pumps, ensuring safe handling.
Documentation: Includes installation, maintenance instructions, and warranty details.
Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.
1. What is the BK2 Orbit Motor?
Advanced disc compensation geroler structure, high volumetric efficiency and long service life
Low startup pressure, smooth low-speed rotation without crawling, stable forward/reverse running
Reinforced output bearing, capable of heavy radial and axial load
Max continuous pressure up to 21MPa, peak pressure reaches 31MPa for heavy overload
Complete displacement lineup and multiple shaft/flange options for flexible matching
Fully interchangeable with Eaton Char-Lynn 2000 series for direct replacement
Compact layout, low noise vibration and reliable anti-leak sealing performance
3. What is the working pressure range of BK2 Orbit Motor ?
Continuous working pressure: 20.5–21 MPa (205–210 bar)
Intermittent pressure: 26–31 MPa (260–310 bar)
Instant peak pressure: Max 31 MPa (310 bar)
Note: Peak pressure is only allowed for short-time overload operation. Long-term running shall stay within continuous rated pressure to extend motor service life.
4. Can BK2 Orbit Motor replace other brands?
Perfect interchange with Eaton Char-Lynn 2000 / 2K series: same 2-hole SAE flange, shaft sizes, port layout and torque-speed performance
Compatible with Danfoss OMS series and M+S MS series orbit motors of matching displacement and mounting standard.
Multiple optional shafts (straight key, involute spline, tapered spline) and customized port threads support matching most domestic Chinese BM2/BMS hydraulic motors.
Identical pressure, torque and speed parameters guarantee consistent machine running performance after replacement.
Custom brake assembly, special flanges and output shafts can be made for non-standard brand models upon request.
6. What is the typical speed range of BK2 Orbit Motor ?
Its rated speed varies by displacement.
The full speed range covers 230 RPM to 865 RPM.
Small-displacement models run faster.
Large-displacement versions output higher torque at lower speeds.
7. Do you provide OEM or customized services?
Yes, we support OEM and ODM customized services for BK2 orbit motors.
Custom output shafts, flanges and port threads are available.
Laser brand logo and customized paint color can be offered.
Matching wet disc brake assembly is optional.
Special specifications can be developed according to your requirements.
8. How can I get a quotation quickly
Please provide the following details:
Model or displacement
Working pressure
Speed
Quantity
We will reply within 12 hours with a competitive quotation.
BK2 Orbit Motor are manufactured in compliance with international standards, ensuring high performance and reliability:
ISO 9001: Certified for quality management systems.
CE Certification: Ensures compliance with European safety, health, and environmental protection standards.
RoHS Compliance: Ensures the pump does not contain hazardous materials.
Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
1.What's our advantages?
Factory established in 2005;
With a great deal of production experience;
80+ employees become the professional team;
Constant updated ERP system ensure efficiency of work;
Sophisticated equipment ehanced the accuracy of products;
Professional salesmen provide the greast service;
With a large number of famous customers all over the world;
Great after-sales service;
With the long term cooperation with famous logistics and express company in China,provide the better goods service.
Small order/sample order,full payment in advance; Big orders send the first payment 30% before the production,and the balance before shippment.We'll show the photos of the products and packages before delivery.
Of course we can. Just send me your logo we can make it for you.
America(40.5%):USA, Canada, Argentina, Brazil
Europe(30.8%):Italy,Germany,England,Holland,Spain,Swiss,Finland,Russia,Poland.
Asia(23.5%):Korea,singapore,India,Turkey,Vietnam,Saudi Arabia,Syria, Israel,Lebanon.
Others(5.8%).
The Green hydraulic pump manufacturing facility is a specialized industrial plant that focuses on producing hydraulic pumps and related components. These factories are equipped with advanced machinery and technology to fabricate high-quality pumps designed for a wide range of applications, from heavy equipment and machinery to automotive and industrial systems.
The production process typically involves precision engineering, where raw materials like metals and alloys are processed into pump components such as gears, pistons, cylinders, and seals. These parts are then assembled into fully functional hydraulic pumps, which are tested for performance and quality control to ensure reliability, efficiency, and durability under various working conditions.
