BZZ2
Green Hydraulic
BZZ2
Standard export carton/plywood case
YES
ISO9001 CE
1 set
Product Description
Available in multiple displacement specifications, the BZZ2 steering unit delivers stable pressure resistance, high volumetric efficiency and long service life. It is perfectly suitable for various agricultural and construction machinery under long-term frequent working conditions.
Mature gerotor stator-rotor structure
Stable output, high volumetric efficiency, low internal leakage, suitable for long-time continuous operation.
Light and flexible steering operation
Low operating torque reduces driver fatigue during long-hour work.
Built-in anti-kickback design
Prevent steering wheel rebound and shaking when driving on rough and bumpy roads.
Emergency manual steering function
Reliable manual control available once hydraulic supply fails to guarantee driving safety.
Standard interchangeable installation
Universal flange and spline shaft, easy replacement with other mainstream orbitrol steering units without modification.
Complete displacement range
Various displacement options to match light, medium and heavy-duty mobile machinery.
Compact and durable structure
Cast iron housing with wear-resistant internal parts, low vibration and noise, long service lifespan.
Specifications
Applications
Light mining wheel vehicles, small port handling machines, small vessel auxiliary steering systems.
Factory&FAQ
BZZ2 Hydraulic Steering Unit are typically packaged securely to prevent damage during transit. The packaging includes:
Protective Wrapping: To safeguard the pump from environmental damage.
Custom Crates: For larger, heavier pumps, ensuring safe handling.
Documentation: Includes installation, maintenance instructions, and warranty details.
Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.
1. What is the BZZ2 Hydraulic Steering Unit ?
The BZZ2 hydraulic steering unit is an open-center reaction type orbital orbitrol steering control unit, built with integrated rotary valve and 6/7 tooth gerotor stator-rotor assembly.
It features steering wheel reaction feedback design, standard universal mounting structure compatible with mainstream orbitrol models. When hydraulic power fails, it can serve as a manual pump for emergency steering. Multiple displacement options from 50ml/r to 400ml/r are available, with max working pressure up to 16MPa. Light operating torque delivers smooth control, widely matched to tractors, loaders, forklifts and other low-speed heavy-duty mobile machinery.
Reliable open-center reaction gerotor structure
Adopts mature 6/7 tooth stator-rotor pair, stable volumetric efficiency and low internal leakage for long continuous operation.
Labor-saving light steering torque
Smooth operation effectively lessens driver fatigue during long-time heavy-duty work.
Anti-kickback steering protection
Prevents steering wheel bounce and vibration when traveling on rough, bumpy terrain.
Safe emergency manual steering
Works as a manual steering pump once hydraulic power fails to avoid out-of-control risks.
Universal interchangeable mounting
Standard flange and spline design, directly replaceable with mainstream orbitrol steering units without structural changes.
Full range of displacement options
Covers 50 to 400 ml/r to fit small, medium and large agricultural & construction machines.
Robust long-lasting build
Cast iron body and wear-resistant internal components ensure low noise, stable performance and extended service life.
3. What is the working pressure range of BZZ2 Hydraulic Steering Unit ?
Maximum continuous rated working pressure: 16 MPa (160 bar / 2320 PSI)
Instant peak withstand pressure: 25 MPa (250 bar / 3625 PSI)
Maximum allowable return line back pressure on T port: 2.0 MPa (20 bar)
4. Can BZZ2 Hydraulic Steering Unit replace other brands?
6. What is the typical speed range of BZZ2 Hydraulic Steering Unit ?
Maximum allowable input rotating speed: 90 rpm
7. Do you provide OEM or customized services?
Yes, we support full OEM and customized services for BZZ2 hydraulic steering units.
For OEM service, we can mark your brand logo and part numbers on the housing, and customize exclusive packaging boxes with your brand artwork under standard specifications.
Customizable items include adjusting pressure parameters, modifying spline sizes and port threads, developing special displacements, and matching internal structures according to special working conditions.
Small MOQ is acceptable for standard OEM orders, while customized non-standard models require negotiable minimum order quantity.
8. How can I get a quotation quickly
Please provide the following details:
Model or displacement
Working pressure
Speed
Quantity
We will reply within 12 hours with a competitive quotation.
BZZ2 Hydraulic Steering Unit are manufactured in compliance with international standards, ensuring high performance and reliability:
ISO 9001: Certified for quality management systems.
CE Certification: Ensures compliance with European safety, health, and environmental protection standards.
RoHS Compliance: Ensures the pump does not contain hazardous materials.
Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
1.What's our advantages?
Factory established in 2005;
With a great deal of production experience;
80+ employees become the professional team;
Constant updated ERP system ensure efficiency of work;
Sophisticated equipment ehanced the accuracy of products;
Professional salesmen provide the greast service;
With a large number of famous customers all over the world;
Great after-sales service;
With the long term cooperation with famous logistics and express company in China,provide the better goods service.
Small order/sample order,full payment in advance; Big orders send the first payment 30% before the production,and the balance before shippment.We'll show the photos of the products and packages before delivery.
Of course we can. Just send me your logo we can make it for you.
America(40.5%):USA, Canada, Argentina, Brazil
Europe(30.8%):Italy,Germany,England,Holland,Spain,Swiss,Finland,Russia,Poland.
Asia(23.5%):Korea,singapore,India,Turkey,Vietnam,Saudi Arabia,Syria, Israel,Lebanon.
Others(5.8%).
The Green hydraulic pump manufacturing facility is a specialized industrial plant that focuses on producing hydraulic pumps and related components. These factories are equipped with advanced machinery and technology to fabricate high-quality pumps designed for a wide range of applications, from heavy equipment and machinery to automotive and industrial systems.
The production process typically involves precision engineering, where raw materials like metals and alloys are processed into pump components such as gears, pistons, cylinders, and seals. These parts are then assembled into fully functional hydraulic pumps, which are tested for performance and quality control to ensure reliability, efficiency, and durability under various working conditions.
