RC-2A
Green Hydraulic
Yes
ISO9001，CE
• Industrial • Energy • Government (Non Aerospace) • HVAC • Mobile • Natural Resources • Transportation (Non Aerospace)
1.Agricultural Equipment 2.Industrial Machinery 3.Construction Equipment 4.Material Handling
Key Shaft and Spline shaft
1 set
Product Description
The RC-2A Hydraulic Gear Pump is a compact and reliable external gear pump designed to provide stable hydraulic flow and consistent pressure for a wide range of applications. Featuring precision-machined gears and a robust housing structure, it ensures smooth operation, high efficiency, and long service life.
| Parameter | Specification |
|---|---|
| Pump Type | External Gear Pump |
| Series | RC-2A |
| Displacement Range | 6 – 20 cc/rev |
| Max. Working Pressure | Up to 250 bar (3625 PSI) |
| Peak Pressure | Up to 280 bar (4060 PSI) |
| Speed Range | 500 – 4000 rpm |
| Min. Speed | 500 rpm |
| Rotation | Clockwise (R) / Counterclockwise (L) |
| Shaft Type | Key / Spline / Taper |
| Mounting Type | Flange / Foot Mount |
| Port Type | BSP / NPT / SAE |
| Working Temperature | -20°C to +80°C |
| Hydraulic Fluid | Mineral Hydraulic Oil |
| Filtration Level | ≤ 25 μm |
| Volumetric Efficiency | ≥ 90% |
| Noise Level | Low Noise Design |
Applications
Construction Equipment
Excavators, loaders, and cranes for lifting and hydraulic actuation.
Agricultural Machinery
Tractors, harvesters, and sprayers for hydraulic power transmission.
Material Handling
Forklifts, pallet trucks, and lifting platforms.
Industrial Machinery
Hydraulic presses, machine tools, and conveyor systems.
Mobile Equipment
Dump trucks, utility vehicles, and small hydraulic systems.
RC-2A Hydraulic Gear Pumps are typically packaged securely to prevent damage during transit. The packaging includes:
Protective Wrapping: To safeguard the pump from environmental damage.
Custom Crates: For larger, heavier pumps, ensuring safe handling.
Documentation: Includes installation, maintenance instructions, and warranty details.
Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.
The RC-2A series can operate up to 250 bar (3625 PSI), with peak pressure reaching 280 bar (4060 PSI) depending on the model.
Common displacement ranges from 6 cc/rev to 20 cc/rev, covering a wide variety of flow requirements.
Yes, it supports custom shaft types, mounting options, and port configurations (BSP, NPT, SAE) for OEM needs.
It is widely used in construction machinery, agriculture, forklifts, industrial equipment, and mobile hydraulic systems.
Standard mineral-based hydraulic oil is recommended for optimal performance and long service life.
Maintain proper filtration (≤25 μm), avoid dry running, ensure correct installation, and perform regular maintenance.
Yes, we support OEM and customization, including nameplate, packaging, and specific performance requirements. Send us your drawings or specifications for evaluation.
Please provide the following details:
Model or displacement
Working pressure
Speed
Quantity
We will reply within 12 hours with a competitive quotation.
The RC-2A pumps are manufactured in compliance with international standards, ensuring high performance and reliability:
ISO 9001: Certified for quality management systems.
CE Certification: Ensures compliance with European safety, health, and environmental protection standards.
RoHS Compliance: Ensures the pump does not contain hazardous materials.
Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
The pump's flow is adjusted by changing the angle of an internal swash plate. As the swash plate angle changes, the stroke length of the pistons varies, which in turn changes the volume of fluid displaced per rotation, allowing the flow rate to adapt to the system's needs.
Factory established in 2005;
With a great deal of production experience;
80+ employees become the professional team;
Constant updated ERP system ensure efficiency of work;
Sophisticated equipment ehanced the accuracy of products;
Professional salesmen provide the greast service;
With a large number of famous customers all over the world;
Great after-sales service;
With the long term cooperation with famous logistics and express company in China,provide the better goods service.
Small order/sample order,full payment in advance; Big orders send the first payment 30% before the production,and the balance before shippment.We'll show the photos of the products and packages before delivery.
Of course we can. Just send me your logo we can make it for you.
America(40.5%):USA, Canada, Argentina, Brazil
Europe(30.8%):Italy,Germany,England,Holland,Spain,Swiss,Finland,Russia,Poland.
Asia(23.5%):Korea,singapore,India,Turkey,Vietnam,Saudi Arabia,Syria, Israel,Lebanon.
Others(5.8%).
The Green hydraulic pump manufacturing facility is a specialized industrial plant that focuses on producing hydraulic pumps and related components. These factories are equipped with advanced machinery and technology to fabricate high-quality pumps designed for a wide range of applications, from heavy equipment and machinery to automotive and industrial systems.
The production process typically involves precision engineering, where raw materials like metals and alloys are processed into pump components such as gears, pistons, cylinders, and seals. These parts are then assembled into fully functional hydraulic pumps, which are tested for performance and quality control to ensure reliability, efficiency, and durability under various working conditions.
Green Hydraulic's manufacturing facilities for hydraulic pumps maintain stringent quality standards, often adhering to international certifications, to meet the expectations of customers in industries such as construction, agriculture, automotive, and manufacturing.
All hydraulic pumps produced by Green Hydraulic have undergone compliance testing, ensuring their quality and reliability.
To meet the diverse needs of different industries, the green hydraulic offer customization options, such as specialized seals, materials, and pump configurations. These facilities often work closely with engineering teams to develop tailored solutions for specific applications, from high-pressure systems to low-flow, high-efficiency pumps.
Each pump undergoes a rigorous quality control process, where pressure tests and performance assessments are conducted to ensure that the pumps meet the required standards for flow rate, pressure capacity, and durability.
