A10VNO28 A10VNO45 A10VNO63 A10VNO85 Piston Pump OVERVIEW

Features and Benefits

• Four displacement options to match different power configurations of mobile equipment.

• High pressure resistance: continuous pressure up to 280 bar (ADU041/049/062), peak pressure reaches 350 bar.

• Load-sensing control reduces energy loss and lowers fuel consumption effectively.

• Reinforced bearings and drive shaft extend service life up to 10,000+ working hours.

• Low noise, compact casting structure, easy installation in limited engine space.

• 1:1 mounting dimensions, splines and oil port layout for direct bolt-on replacement.

• Strict factory testing, stable performance under harsh working conditions

Specifications A10VNO28 A10VNO45 A10VNO63 A10VNO85 Piston Pump

Applications

Packaging & Delivery

Mobile Piston Pump ADU041 ADU049 ADU062 ADU080 are typically packaged securely to prevent damage during transit. The packaging includes:

Protective Wrapping: To safeguard the pump from environmental damage.

Custom Crates: For larger, heavier pumps, ensuring safe handling.

Documentation: Includes installation, maintenance instructions, and warranty details.

Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.

Mobile Piston Pump ADU041 ADU049 ADU062 ADU080 FAQ:

1. What is the Mobile Piston Pump ADU041 ADU049 ADU062 ADU080 ?

• Four displacement options: 41cc, 49cc, 62cc, 80cc to fit different mobile equipment power demands.

• High pressure performance: continuous pressure up to 280 bar and peak pressure up to 350 bar.

• Load-sensing control saves power and reduces fuel consumption effectively.

• Reinforced rotating components improve durability under heavy working conditions.

• Standard SAE mounting dimensions, fully interchangeable with original Eaton pumps without modification.

• Compact housing design, low noise and stable operation for agricultural and construction machinery.




3. What is the working pressure range of Mobile Piston Pump ADU041 ADU049 ADU062 ADU080 ?

    ADU041 / ADU049 / ADU062

• Continuous working pressure: 280 bar (4060 PSI)

• Intermittent pressure: 320 bar (4600 PSI)

• Short peak pressure: 350 bar (5000 PSI)

  ADU080

• Continuous working pressure: 210 bar (3050 PSI)

• Intermittent pressure: 230 bar (3335 PSI)

• Short peak pressure: 250 bar (3625 PSI)



4. Can Mobile Piston Pump ADU041 ADU049 ADU062 ADU080 replace other brands?

• Preferred oil grade: ISO VG 46 anti-wear mineral hydraulic oil for tractors, loaders and regular mobile machinery.

• Alternative grade: ISO VG 68 AW hydraulic oil for continuous high temperature and heavy loads.

• Oil requirement: Must contain anti-wear, anti-oxidation and anti-rust additives.

• Fluid cleanliness: Maintain oil purity at NAS 8 or better to reduce internal wear.

• Working oil temperature: 25°C ~ 85°C.

6. What is the typical speed range of Mobile Piston Pump ADU041 ADU049 ADU062 ADU080 ?


        ADU041 / ADU049

• Continuous rated speed: 2650 rpm


• Intermittent high speed: 2950 rpm (short-time only)

• Minimum stable speed: 600 rpm



        ADU062

• Continuous rated speed: 2600 rpm

• Intermittent high speed: 2800 rpm (short-time only)

• Minimum stable speed: 600 rpm



  ADU080

• Continuous rated speed: 2200 rpm

• Intermittent high speed: 1800 rpm under low inlet pressure

• Minimum stable speed: 600 rpm

  General rule

• Normal working range: 800 rpm up to the rated continuous speed.


• Do not run at maximum intermittent speed continuously to avoid cavitation and premature wear.

7. Do you provide OEM or customized services?

8. How can I get a quotation quickly

Please provide the following details:

• Model or displacement

• Working pressure

• Speed

• Quantity
  We will reply within 12 hours with a competitive quotation.




Certifications & Quality Assurance

Mobile Piston Pump ADU041 ADU049 ADU062 ADU080  are manufactured in compliance with international standards, ensuring high performance and reliability:

ISO 9001: Certified for quality management systems.

CE Certification: Ensures compliance with European safety, health, and environmental protection standards.

RoHS Compliance: Ensures the pump does not contain hazardous materials.

Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
