A10V(S)O 31/32/52&53
Green Hydraulic
A10V(S)O 31/32/52&53
Standard export carton/plywood case
YES
ISO9001 CE
1 set
Product Description
Optimized piston & slipper friction pair design, strong wear resistance and anti-cavitation capacity;
Double drain port layout to effectively reduce internal oil pressure and extend seal service life;
Input shaft bears both radial and axial force, strong environmental adaptability;
Cast iron pump housing with good vibration damping and pressure-bearing performance.
Specifications
Displacement range: 18 ~ 140 cc/rev
Feature: Classic mature structure, with through-drive interface, full range of control valves, complete aftermarket spare parts
Displacement range: 45 ~ 180 cc/rev
Feature: Optimized noise reduction & volumetric efficiency, fully interchangeable installation size with /31 series
Displacement: Fixed 10 cc/rev (small displacement only)
Feature: Fast response, compact layout, applied for precision auxiliary hydraulic circuits
Displacement: Fixed 10 cc/rev
Feature: Upgrade based on /52, FKM fluororubber seals, stronger high-temperature & deteriorated oil resistance
Dual drain port design for lower internal casing pressure
Input shaft supports radial & axial composite load
High-strength cast iron pump housing with good shock resistance
Standard friction pairs: piston, slipper, cylinder block, valve plate
Applications
Mini & small excavators, road rollers, asphalt pavers, road sweepers and pavement maintenance vehicles
Concrete mixers, concrete delivery pumps and mortar conveying equipment
Aerial work platforms, forklifts and other mobile engineering vehicles
Hydraulic power units for automated production lines
Injection molding machines, hydraulic presses and metallurgical auxiliary hydraulic systems
Machine tool hydraulic driving and clamping oil circuits
Factory&FAQ
A10V Pump A10V(S)O31/32/52&53 are typically packaged securely to prevent damage during transit. The packaging includes:
Protective Wrapping: To safeguard the pump from environmental damage.
Custom Crates: For larger, heavier pumps, ensuring safe handling.
Documentation: Includes installation, maintenance instructions, and warranty details.
Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.
1. What is the A10V Pump A10V(S)O31/32/52&53 ?
The 31 version is the classic mature model with complete displacement specifications; the 32 version improves noise reduction and working efficiency while keeping interchangeable installation dimensions.
The 52 and 53 versions are small-displacement pumps (10cc only), where 53 upgrades the sealing material for better resistance to high temperature and deteriorated hydraulic oil.
Multiple control modes (DR, DFR, DFLR, ED) are optional, widely matched for construction machinery and industrial hydraulic systems.
2. What makes the A10V Pump A10V(S)O31/32/52&53 ?
The 31 & 32 main series use high-strength cast iron housings to bear high system pressure, equipped with multi-type integrated control valves for automatic load adjustment and energy saving.
The 52 and 53 small-displacement models feature compact layout; the 53 model is fitted with FKM fluororubber seals to adapt to harsh oil and temperature conditions.
Double drain ports, load-resistant input shaft and standardized SAE mounting structure jointly guarantee stable operation, strong durability and universal replaceability for construction machinery and industrial hydraulic equipment.
3. What is the working pressure range of A10V Pump A10V(S)O31/32/52&53 ?
Continuous rated pressure: 280 bar = 4061.06 psi
Instantaneous peak pressure: 350 bar = 5076.33 psi
All versions (31/32/52/53) share this unified pressure parameter standard.
4. Can Hydraulic A10V Pump A10V(S)O31/32/52&53 replace other brands?
Original standard benchmark: It is designed strictly following the dimensional drawing of Rexroth A10VSO series. The mounting flange, input shaft size, oil port position, control valve interface and installation overall dimension are fully consistent with original Rexroth pumps, which can be directly installed without modifying equipment structures.
Inter-brand substitution: Most domestic peer brands that copy Rexroth A10VSO structure share unified external dimensions, so this pump is interchangeable with those generic A10VSO pumps from different manufacturers.
Precondition for replacement: Match the exact series code (31/32/52/53), displacement value, control type (DR/DFR/DFLR/ED) and rotation direction before replacement.
Pressure parameter consistency: Rated pressure 280 bar (4061.06 psi), peak pressure 350 bar (5076.33 psi), consistent with original design pressure, meeting the original system working requirements.
5. What is the typical speed range of A10V Pump A10V(S)O31/32/52&53 ?
The standard allowable operating speed range for the A10V(S)O 31/32/52&53 pump series is 500 rpm to 3000 rpm.Stable working performance can be maintained within this whole speed interval under rated working pressure.
6. Do you provide OEM or customized services?
OEM service: We can print your brand logo, label, company part number on the pump housing and nameplate; neutral packaging or branded packaging is available as requested.
Customized items: Customize control modes, rotation direction, shaft specifications, seal materials (FKM/NBR), paint color and outer appearance. We also accept customized flow and pressure parameters for special working conditions.
Custom drawings and samples can be developed according to your technical requirements for long-term matching use.
7. How can I get a quotation quickly
Please provide the following details:
Model or displacement
Working pressure
Speed
Quantity
We will reply within 12 hours with a competitive quotation.
A10V Pump A10V(S)O31/32/52&53 are manufactured in compliance with international standards, ensuring high performance and reliability:
ISO 9001: Certified for quality management systems.
CE Certification: Ensures compliance with European safety, health, and environmental protection standards.
RoHS Compliance: Ensures the pump does not contain hazardous materials.
Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
1.What's our advantages?
Factory established in 2005;
With a great deal of production experience;
80+ employees become the professional team;
Constant updated ERP system ensure efficiency of work;
Sophisticated equipment ehanced the accuracy of products;
Professional salesmen provide the greast service;
With a large number of famous customers all over the world;
Great after-sales service;
With the long term cooperation with famous logistics and express company in China,provide the better goods service.
Small order/sample order,full payment in advance; Big orders send the first payment 30% before the production,and the balance before shippment.We'll show the photos of the products and packages before delivery.
Of course we can. Just send me your logo we can make it for you.
America(40.5%):USA, Canada, Argentina, Brazil
Europe(30.8%):Italy,Germany,England,Holland,Spain,Swiss,Finland,Russia,Poland.
Asia(23.5%):Korea,singapore,India,Turkey,Vietnam,Saudi Arabia,Syria, Israel,Lebanon.
Others(5.8%).
The Green hydraulic pump manufacturing facility is a specialized industrial plant that focuses on producing hydraulic pumps and related components. These factories are equipped with advanced machinery and technology to fabricate high-quality pumps designed for a wide range of applications, from heavy equipment and machinery to automotive and industrial systems.
The production process typically involves precision engineering, where raw materials like metals and alloys are processed into pump components such as gears, pistons, cylinders, and seals. These parts are then assembled into fully functional hydraulic pumps, which are tested for performance and quality control to ensure reliability, efficiency, and durability under various working conditions.
