CBD2-F200 Series Gear Pump Direction of Rotation

CBD2-F200 Series Gear Pump Overview

The CBD2-F200 Series Gear Pump is a high-performance double hydraulic gear pump designed for stable flow output and efficient hydraulic power transmission. Featuring a compact structure, high volumetric efficiency, low noise, and reliable pressure performance, it is widely used in construction machinery, agricultural equipment, forklifts, hydraulic power units, and industrial hydraulic systems.

The pump adopts a durable aluminum alloy housing and precision-machined gears to ensure smooth operation, long service life, and stable performance under demanding working conditions. Multiple displacement options, shaft types, and rotation directions are available to meet different hydraulic system requirements.

Applications

Winches, oil field and drilling

equipment, earthmoving and

construction equipment, die

casting, molding machines, press

machines, trash compactors, balers

and primary metals

Packaging & Delivery

Gear Pumps are typically packaged securely to prevent damage during transit. The packaging includes:

Protective Wrapping: To safeguard the high-precision pump body and shaft from moisture and environmental damage.

Custom Cartons or Crates: Individual reinforced packaging with shock-absorbent inserts for single pumps, and sturdy wooden crates for bulk or tandem pump orders to ensure safe handling.

Documentation: Includes technical data sheets, installation guides, and quality inspection certificates.

Delivery time depends on the specific model, port configurations, and destination but typically ranges from 1 to 4 weeks from the order date.

CBD2-F200 Series Gear Pump FAQ

1. What is the CBD2-F200 Series Gear Pump?

The CBD2-F200 Series is a compact double hydraulic gear pump designed for stable flow output and efficient hydraulic power transmission in mobile and industrial hydraulic systems.

2. What are the main features of the CBD2-F200 Series?

Main features include:

• Double pump structure

• High volumetric efficiency

• Low noise operation

• Compact and lightweight design

• Stable pressure performance

• Long service life

3. What pressure range does the pump support?

The pump has a rated pressure of 20 MPa and a maximum pressure of 25 MPa.

4. What is the operating speed range?

The CBD2-F200 Series supports:

• Minimum speed: 600 r/min

• Rated speed: 2000 r/min

• Maximum speed: up to 5100 r/min

5. What displacement options are available?

The series provides displacement options from 1.3 mL/r to 6.1 mL/r for different hydraulic system requirements.

6. What applications is the pump suitable for?

Typical applications include:

• Construction machinery

• Agricultural equipment

• Forklifts

• Hydraulic power units

• Industrial hydraulic systems

7. What port types are available?

The standard port configuration includes:

• Inlet: 3/4-16-UNF-2B

• Outlet: 9/16-18-UNF-2B

8. Can the shaft type and rotation direction be customized?

Yes. Different shaft types and clockwise or counterclockwise rotation options are available according to customer requirements.

9. What hydraulic fluids are recommended?

The pump is suitable for standard anti-wear hydraulic oil and industrial hydraulic fluids.

10. How can the service life of the pump be extended?

To ensure long service life:

• Keep hydraulic oil clean

• Avoid dry running

• Regularly inspect seals and fittings

• Use proper filtration systems

• Perform routine maintenance regularly
