PGP076
Green Hydraulic
PGP076
Standard export carton/plywood case
Yes
ISO9001，CE
• Industrial • Energy • Government (Non Aerospace) • HVAC • Mobile • Natural Resources • Transportation (Non Aerospace)
1. Industrial Hydraulic Systems 2. Mobile Equipment (Industrial Vehicles) 3. Construction and Engineering Machinery 4. Metallurgy Industry
Key Shaft and Spline shaft
1 set
Product Description
| Gear Width (in) | Displacement | Displacement (cc/rev) | Max. Pressure (psi/bar) | Max. Speed (RPM) |
| 1.00" | 3.86 | 63.3 | 2500 / 172 | 2400 |
| 1.25" | 4.82 | 79.1 | 2500 / 172 | 2400 |
| 1.50" | 5.79 | 94.9 | 2500 / 172 | 2400 |
| 1.75" | 6.75 | 110.7 | 2500 / 172 | 2400 |
| 2.00" | 7.72 | 126.5 | 2500 / 172 | 2400 |
| 2.25" | 8.68 | 142.3 | 2250 / 155 | 2400 |
| 2.50" | 9.65 | 158.1 | 2000 / 138 | 2400 |
Applications
Vocational & Service Trucks: The primary choice for utility cranes, aerial lifts, tire service trucks, and roll-off systems, where the compact PGP076 design integrates seamlessly with PTO units to provide consistent lifting and handling power.
Snow & Ice Control: Optimized for salt spreaders, sanders, and small plow systems, with cast iron construction and roller bearings ensuring long service life in corrosive, high-cycle winter maintenance environments.
Refuse & Waste Handling: Widely used in refuse trucks and moving floor systems, where the pump handles frequent high-pressure cycles and fluid contamination to support compaction and unloading operations.
Oil & Gas Field Equipment: Engineered for service trucks and hydraulic power units, the PGP076 withstands harsh field conditions, delivering stable performance for well service, pumping, and fluid transfer applications.
Winch & Recovery Systems: A trusted option for heavy-duty winches and recovery equipment, providing smooth, high-torque flow under variable load conditions.
Agricultural & Off-Road Equipment: Suitable for spreaders, implement hydraulics, and small off-road machinery, where the pump’s robust build resists fluid contamination and shock loads common in outdoor environments.
PGP076 pumps are typically packaged securely to prevent damage during transit. The packaging includes:
Protective Wrapping: To safeguard the pump from environmental damage.
Custom Crates: For larger, heavier pumps, ensuring safe handling.
Documentation: Includes installation, maintenance instructions, and warranty details.
Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.
Rugged Cast Iron Construction: Unlike aluminum pumps that suffer from "body stretching" at high pressures, the PGP076’s cast iron frame maintains tight internal clearances, ensuring longer service life under continuous high-pressure duty cycles.
Heavy-Duty Roller Bearings: Its robust roller bearing design provides excellent load capacity and resistance to fluid contamination, outperforming standard aluminum pumps in high-cycle, dirty-fluid applications.
Modular Installation Flexibility: With multiple standard porting configurations (side, rear, split flange) and versatile SAE mounting options, the PGP076 offers far greater installation flexibility in cramped chassis environments than many fixed-port aluminum designs.
Continuous Pressure: Up to 3,000 PSI (207 bar).
Intermittent/Peak Pressure: Up to 3,500 PSI (241 bar).
This robust rating makes the PGP076 ideal for powering high-force lifting, compaction, and actuation systems on vocational and industrial equipment.
Muncie PH1 / Commercial Intertech P315 Series
Metaris MH315 Series
Permco P1900 / P2100 Series
To ensure a successful swap, verify the Mounting Flange (SAE “A”, “B”, or “C”), Shaft Type (splined/tapered) and Displacement (cc/rev) to match your existing system.
Oil Type: Premium mineral-based hydraulic fluids with strong Anti-Wear (AW) and anti-oxidation additive packages.
Viscosity: Standard ISO VG32 to VG68. The optimal operating range is 100 to 150 SUS (20 to 30 cSt), though it can handle cold starts up to 2,000 SUS (430 cSt).
Filtration: Cleanliness is vital for long bearing life. A minimum filtration of ISO 4406 18/16/13 is recommended to prevent abrasive particles from damaging internal components.
Rated Continuous Speed: Up to 2,400 RPM.
Maximum Intermittent Speed: Up to 3,000 RPM (depending on displacement and application).
Always match the pump speed to your system requirements to maximize efficiency and service life.
Yes, we support OEM and customization, including nameplate, packaging, and specific performance requirements. Send us your drawings or specifications for evaluation.
Please provide the following details:
Model or displacement
Working pressure
Speed
Quantity
We will reply within 12 hours with a competitive quotation.
PGP076 pumps are manufactured in compliance with international standards, ensuring high performance and reliability:
ISO 9001: Certified for quality management systems.
CE Certification: Ensures compliance with European safety, health, and environmental protection standards.
RoHS Compliance: Ensures the pump does not contain hazardous materials.
Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
The pump's flow is adjusted by changing the angle of an internal swash plate. As the swash plate angle changes, the stroke length of the pistons varies, which in turn changes the volume of fluid displaced per rotation, allowing the flow rate to adapt to the system's needs.
Factory established in 2005;
With a great deal of production experience;
80+ employees become the professional team;
Constant updated ERP system ensure efficiency of work;
Sophisticated equipment ehanced the accuracy of products;
Professional salesmen provide the greast service;
With a large number of famous customers all over the world;
Great after-sales service;
With the long term cooperation with famous logistics and express company in China,provide the better goods service.
Small order/sample order,full payment in advance; Big orders send the first payment 30% before the production,and the balance before shippment.We'll show the photos of the products and packages before delivery.
Of course we can. Just send me your logo we can make it for you.
America(40.5%):USA, Canada, Argentina, Brazil
Europe(30.8%):Italy,Germany,England,Holland,Spain,Swiss,Finland,Russia,Poland.
Asia(23.5%):Korea,singapore,India,Turkey,Vietnam,Saudi Arabia,Syria, Israel,Lebanon.
Others(5.8%).
The Green hydraulic pump manufacturing facility is a specialized industrial plant that focuses on producing hydraulic pumps and related components. These factories are equipped with advanced machinery and technology to fabricate high-quality pumps designed for a wide range of applications, from heavy equipment and machinery to automotive and industrial systems.
The production process typically involves precision engineering, where raw materials like metals and alloys are processed into pump components such as gears, pistons, cylinders, and seals. These parts are then assembled into fully functional hydraulic pumps, which are tested for performance and quality control to ensure reliability, efficiency, and durability under various working conditions.
Green Hydraulic's manufacturing facilities for hydraulic pumps maintain stringent quality standards, often adhering to international certifications, to meet the expectations of customers in industries such as construction, agriculture, automotive, and manufacturing.
All hydraulic pumps produced by Green Hydraulic have undergone compliance testing, ensuring their quality and reliability.
To meet the diverse needs of different industries, the green hydraulic offer customization options, such as specialized seals, materials, and pump configurations. These facilities often work closely with engineering teams to develop tailored solutions for specific applications, from high-pressure systems to low-flow, high-efficiency pumps.
Each pump undergoes a rigorous quality control process, where pressure tests and performance assessments are conducted to ensure that the pumps meet the required standards for flow rate, pressure capacity, and durability.
