GHP1 Series Marzocchi Hydraulic Gear Pump

GHP1 SERIES Gear Pump  Overview

The Marzocchi GHP1 is a high-performance, fixed-displacement gear pump engineered for demanding hydraulic systems that require a combination of high-pressure capability and long-term durability. As part of the prestigious GHP series, the GHP1 features a hybrid material construction that delivers superior mechanical strength, making it an ideal choice for heavy-duty mobile equipment, agricultural machinery, and high-cycle industrial power units.

Features and Benefits

• Robust Hybrid Construction for High Pressures:
  Unlike standard aluminum pumps, the GHP1 combines a high-strength extruded aluminum alloy body with  spheroidal cast iron flanges and rear covers. This hybrid design provides the rigidity necessary to handle continuous operating pressures of up to  270 bar (3,915 psi) while maintaining a favorable power-to-weight ratio.
• High Volumetric and Mechanical Efficiency:
  The GHP1 utilizes a sophisticated axial compensation system with special pressure-balanced bushings. This technology minimizes internal fluid bypass and friction losses, ensuring consistent performance and high energy efficiency even at high temperatures and low speeds.
• Advanced Low-Noise Gear Profile:
  Equipped with hardened and ground steel gears that feature a specialized tooth profile, the GHP1 is designed to minimize pressure ripples and operational vibration. This results in a significant reduction in noise levels, enhancing operator comfort in mobile applications.
• Exceptional Durability and Service Life:
  The pump is built with large-diameter journals and high-load capacity bearings to reduce surface pressure and wear. High-quality sealing systems and precision-machined components allow the GHP1 to excel in heavy-duty cycles and harsh environments where reliability is critical.
• Flexible Configuration and Modular Design:
  The GHP1 series offers a versatile range of displacements (from  1.4 to 13.8 cc/rev) and supports multiple international mounting standards, including  European, SAE, and German flanges. With various shaft types (tapered, splined, or keyed) and the ability to be configured into multiple-stage pumps, it integrates seamlessly into diverse hydraulic circuit designs.

Model Codes

Applications

Packaging & Delivery

GHP1 pumps are typically packaged securely to prevent damage during transit. The packaging includes:

Protective Wrapping: To safeguard the pump from environmental damage.

Custom Crates: For larger, heavier pumps, ensuring safe handling.

Documentation: Includes installation, maintenance instructions, and warranty details.

Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.

GHP1 Gear Pump  FAQ

1. What are GHP1 series gear pumps

2. What makes the GHP1 different from standard aluminum gear pumps

4. Can GHP1 pumps replace other brands

5. What hydraulic oil is suitable for GHP1 gear pumps

Yes, we support OEM and customization, including nameplate, packaging, and specific performance requirements. Send us your drawings or specifications for evaluation.

8. How can I get a quotation quickly

Please provide the following details:

• Model or displacement

• Working pressure

• Speed

• Quantity
  We will reply within 12 hours with a competitive quotation.




Certifications & Quality Assurance

GHP1 pumps are manufactured in compliance with international standards, ensuring high performance and reliability:

ISO 9001: Certified for quality management systems.

CE Certification: Ensures compliance with European safety, health, and environmental protection standards.

RoHS Compliance: Ensures the pump does not contain hazardous materials.

Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.

FAQ

1.How does the variable displacement work?

The pump's flow is adjusted by changing the angle of an internal swash plate. As the swash plate angle changes, the stroke length of the pistons varies, which in turn changes the volume of fluid displaced per rotation, allowing the flow rate to adapt to the system's needs.

2.What's our advantages?

Factory established in 2005;

With a great deal of production experience;

80+ employees become the professional team;

Constant updated ERP system ensure efficiency of work;

Sophisticated equipment ehanced the accuracy of products;

Professional salesmen provide the greast service;

With a large number of famous customers all over the world;

Great after-sales service;

With the long term cooperation with famous logistics and express company in China,provide the better goods service.

3.What is your payment terms?

Small order/sample order,full payment in advance; Big orders send the first payment 30% before the production,and the balance before shippment.We'll show the photos of the products and packages before delivery.

4.Can you make my own brand on the products?

Of course we can. Just send me your logo  we can make it for you.

5.What is our main export market?

America(40.5%):USA, Canada, Argentina, Brazil

Europe(30.8%):Italy,Germany,England,Holland,Spain,Swiss,Finland,Russia,Poland.

Asia(23.5%):Korea,singapore,India,Turkey,Vietnam,Saudi Arabia,Syria, Israel,Lebanon.

Others(5.8%).

The Green hydraulic pump manufacturing facility is a specialized industrial plant that focuses on producing hydraulic pumps and related components. These factories are equipped with advanced machinery and technology to fabricate high-quality pumps designed for a wide range of applications, from heavy equipment and machinery to automotive and industrial systems.

The production process typically involves precision engineering, where raw materials like metals and alloys are processed into pump components such as gears, pistons, cylinders, and seals. These parts are then assembled into fully functional hydraulic pumps, which are tested for performance and quality control to ensure reliability, efficiency, and durability under various working conditions.

Green Hydraulic's manufacturing facilities for hydraulic pumps maintain stringent quality standards, often adhering to international certifications, to meet the expectations of customers in industries such as construction, agriculture, automotive, and manufacturing.

All hydraulic pumps produced by Green Hydraulic have undergone compliance testing, ensuring their quality and reliability.

To meet the diverse needs of different industries, the green hydraulic offer customization options, such as specialized seals, materials, and pump configurations. These facilities often work closely with engineering teams to develop tailored solutions for specific applications, from high-pressure systems to low-flow, high-efficiency pumps.

Each pump undergoes a rigorous quality control process, where pressure tests and performance assessments are conducted to ensure that the pumps meet the required standards for flow rate, pressure capacity, and durability.
