CBK-F100 Series Gear Pump - Oem Trailer Hydraulic Gear Pump

CBK-F100 Series Gear Pumps are engineered for high-pressure performance, exceptional reliability, and long service life. Designed with a high-strength aluminum alloy body and precision-engineered gears, thesepumps provide consistent hydraulic power for material handling, construction, and agricultural machinery, making them the preferred choice for OEM replacements in brands like Toyota, Komatsu, and Mitsubishi.


  • CBK-F100 Series Gear Pump

  • CBK-F100 Series Gear Pump

  • Standard export carton/plywood case

  • CBK-F100 Series Gear Pump

  • Yes

  • ISO9001, CE

  • • Industrial • Energy • Government (Non Aerospace) • HVAC • Mobile • Natural Resources • Transportation (Non Aerospace)

  • 1. Industrial Hydraulic Systems 2. Mobile Equipment (Industrial Vehicles) 3. Construction and Engineering Machinery 4. Metallurgy Industry

  • Key Shaft and Spline shaft

  • 1 set

Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Product Description

CBK-F100 Series Gear Pump

Overview

CBK-F100 Series Gear Pumps are engineered for high-pressure performance, exceptional reliability, and long service life. Designed with a high-strength aluminum alloy body and precision-engineered gears, thesepumps provide consistent hydraulic power for material handling, construction, and agricultural machinery, making them the preferred choice for OEM replacements in brands like Toyota, Komatsu, and Mitsubishi.


CBK-F100

Features and Benefits

  • Extended Pump Life:

    Exceptional durability achieved through high-grade wear-resistant materials, specialized surface-treated gears, and the use of high-load DU bushings for superior lubrication.

  • Quiet and Smooth Operation:

    Advanced gear tooth profiles and a precision-machined housing reduce fluid pulsation and mechanical vibration, maintaining low noise levels during high-pressure operation.

  • High Efficiency & Energy Saving:

    Features a pressure-loading design that maintains high volumetric and mechanical efficiency, minimizing internal leakage and heat generation.


  • Compact & Modular Design:

    Standardized ISO and SAE mounting flanges and shaft options allow for easy installation in tight spaces and seamless integration into existing systems.


  • Versatile Combinations:

    Supports tandem (double) or triple pump configurations, providing a cost-effective and flexible solution for multi-circuit hydraulic packages.


Model Codes

CBK-F100 CODES


Specifications

Models 排量 (cc/rev) Displacement 额定压力 Rated (MPa) 最大压力 Max (MPa) 额定转速 Rated (r/min) 最大转速 Max (r/min) 最小转速 Min (r/min) 中作油液 (mm²/s) In the oil 工作油温 (℃) Working oil temperature 工作油液过滤精度 (μm) Oil filter precision work 容积效率 Volumetric Efficiency (≥%) 重量 (kg) Weight
CBF-F410-AL** 4.25 25 28 3500 4000 1400 20~43 液压油 Hydraulic oil -20~80 ≤25 ≥90 2.25
CBF-F412.5-AL** 6.4 25 28 3500 4000 1400 20~43 液压油 Hydraulic oil -20~80 ≤25 ≥90 2.4
CBF-F414-AL** 8.1 25 28 3500 4000 1400 20~43 液压油 Hydraulic oil -20~80 ≤25 ≥90 2.55
CBF-F416-AL** 10 25 28 3000 3500 1200 20~43 液压油 Hydraulic oil -20~80 ≤25 ≥90 2.7
CBF-F418-AL** 12.6 25 28 3000 3500 1200 20~43 液压油 Hydraulic oil -20~80 ≤25 ≥90 2.85
CBF-F420-AL** 15.9 25 28 2000 3000 1000 20~43 液压油 Hydraulic oil -20~80 ≤25 ≥90 3.05
CBF-F425-AL** 19.9 20 25 2000 3000 1000 20~43 液压油 Hydraulic oil -20~80 ≤25 ≥90 3.2
CBF-F432-AL** 25 16 20 2000 2500 800 20~43 液压油 Hydraulic oil -20~80 ≤25 ≥90 3.5


Factory&FAQ

CBK-F100 Series Gear Pump FAQ

1. What is the CBK-F100 Series Gear Pump used for?
CBK-F100 Series gear pumps are widely used in tractors, forklifts, construction machinery, and hydraulic power units for reliable fluid power transmission.

2. What are the main features of the CBK-F100 gear pump?
It features compact design, stable flow output, high volumetric efficiency, low noise, and durable cast/aluminum construction.

3. What hydraulic oil is suitable for the CBK-F100 Series?
It is generally compatible with mineral-based hydraulic oils and anti-wear hydraulic fluids recommended by the hydraulic system manufacturer.

4. Can the CBK-F100 gear pump operate in both rotation directions?
Yes, clockwise and counterclockwise rotation options are available depending on model configuration.

5. What causes low pressure or reduced flow in a CBK-F100 pump?
Common causes include suction blockage, air ingress, internal gear wear, contaminated oil, or incorrect rotation.

6. How should the CBK-F100 gear pump be maintained?
Maintain clean hydraulic oil, inspect seals and bearings regularly, replace filters, and avoid dry running or cavitation to extend pump life.

7. Is the CBK-F100 Series suitable for high-pressure applications?
Yes, it is designed for medium to high-pressure hydraulic systems within rated operating limits.

8. Can you provide replacement or OEM-compatible CBK-F100 pumps?
Yes, OEM replacement and customized compatible pumps are available with different displacement, shaft, and mounting options.

Certifications & Quality Assurance

Charge pumps are manufactured in compliance with international standards, ensuring high performance and reliability:

ISO 9001: Certified for quality management systems.

CE Certification: Ensures compliance with European safety, health, and environmental protection standards.

RoHS Compliance: Ensures the pump does not contain hazardous materials.

Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.

Green Hydraulic Patent Certificate
