CBQ-F500 Series Gear Pump
CBQ-F500 Series Gear Pump
Standard export carton/plywood case
Yes
ISO9001, CE
• Industrial • Energy • Government (Non Aerospace) • HVAC • Mobile • Natural Resources • Transportation (Non Aerospace)
1. Industrial Hydraulic Systems 2. Mobile Equipment (Industrial Vehicles) 3. Construction and Engineering Machinery 4. Metallurgy Industry
Key Shaft and Spline shaft
1 set
Product Description
The CBQ-F500 Series Gear Pump is a high-pressure external hydraulic gear pump designed for stable flow output and reliable hydraulic power transmission. Featuring a high-strength aluminum alloy housing, precision-machined gears, high volumetric efficiency, and low noise operation, the CBQ-F500 Series is widely used in forklifts, construction machinery, agricultural equipment, hydraulic power units, and industrial hydraulic systems. It offers compact structure, smooth performance, easy installation, and long service life under demanding working conditions.
Specifications
| Models | Nominal displacement (mL/r) | Pressure(MPa) - Rated | Pressure(MPa) - Max | Rotation speed(r/min) - Min | Rotation speed(r/min) - Rated | Rotation speed(r/min) - Max | Volumetric efficiency | L1 | L | h - 矩形法兰 (Rectangle) | h - 菱形法兰 (Oval) | D - 进油口 (Inlet) | D - 出油口 (Outlet) | weight (kg) |
| CBQ-F520-F* | 20 | 25 | 28 | 600 | 2500 | 3000 | 92 | 62.5 | 129 | 23 | 15 | 25 | 20 | 5.7 |
| CBQ-F525-F* | 25 | 25 | 28 | 600 | 2500 | 3000 | 92 | 64.5 | 133 | 23 | 15 | 25 | 20 | 6 |
| CBQ-F532.5-F* | 32 | 25 | 28 | 600 | 2500 | 3000 | 93 | 67 | 138 | 23 | 15 | 30 | 20 | 6.3 |
| CBQ-F540-F* | 40 | 25 | 28 | 600 | 2500 | 3000 | 93 | 69.5 | 143 | 23 | 15 | 30 | 20 | 6.8 |
| CBQ-F550-F* | 50 | 20 | 25 | 600 | 2500 | 3000 | 93 | 73 | 150 | 23 | 15 | 35 | 25 | 7.3 |
| CBQ-F563-F* | 63 | 20 | 25 | 500 | 2000 | 2500 | 93 | 77.5 | 159 | 23 | 15 | 35 | 25 | 8 |
Application
Applications
Winches, oil field and drilling
equipment, earthmoving and
construction equipment, die
casting, molding machines, press
machines, trash compactors, balers
and primary metals
Factory&FAQ
The CBQ-F500 Series is a compact high-pressure external hydraulic gear pump used for hydraulic oil transmission in mobile and industrial hydraulic systems.
Main features include:
High-strength aluminum alloy housing
High volumetric efficiency
Low noise operation
Stable pressure performance
Compact and lightweight structure
Long service life
Typical applications include:
Forklifts
Agricultural machinery
Construction equipment
Hydraulic power units
Industrial hydraulic systems
Common models include:
CBQ-F520
CBQ-F525
CBQ-F532
CBQ-F540
CBQ-F550
CBQ-F563
The CBQ-F500 Series is designed for high-pressure hydraulic applications with stable pressure output and reliable performance.
The pump can be supplied with multiple shaft types including:
Flat key shaft
Spline shaft
Taper shaft
SAE shaft
Yes. Clockwise (R) and counterclockwise (L) rotation versions are available according to installation requirements.
The pump is suitable for standard hydraulic oil and anti-wear hydraulic fluids used in industrial and mobile hydraulic systems.
Recommended maintenance includes:
Keeping hydraulic oil clean
Avoiding dry running
Regularly inspecting seals and fittings
Using proper filtration systems
Performing routine maintenance
Advantages include:
Stable flow output
High working efficiency
Smooth operation
Easy maintenance
Reliable performance in heavy-duty conditions
