CBF-F4
Green Hydraulic
1
Product Description
CBF-F4 hydraulic gear pumps are compact external gear pumps designed for stable flow output, reliable pressure performance, and long service life. They are widely used in forklifts, agricultural machinery, loaders, and hydraulic power units.
Stable and efficient hydraulic output
Compact and durable gear construction
Low noise and reliable performance
Easy installation and maintenance
| Model | Displacement (cc/rev) | Rated Pressure (MPa) | Max Pressure (MPa) | Min Speed (rpm) | Rated Speed (rpm) | Max Speed (rpm) | Vol. Eff. (%) | L1 (mm) | L (mm) | Inlet Port | Outlet Port | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CBF-F410-AL** | 10 | 20 | 25 | 800 | 2500 | 3000 | 92 | 55 | 114 | M22×1.5 | M18×1.5 | 2.25 |
| CBF-F412.5-AL** | 12.5 | 20 | 25 | 800 | 2500 | 3000 | 92 | 56.3 | 116.5 | M22×1.5 | M18×1.5 | 2.40 |
| CBF-F414-AL** | 14 | 20 | 25 | 800 | 2500 | 3000 | 92 | 57.3 | 118.5 | M22×1.5 | M18×1.5 | 2.55 |
| CBF-F416-AL** | 16 | 20 | 25 | 800 | 2500 | 3000 | 92 | 58.3 | 120 | M27×2 | M22×1.5 | 2.70 |
| CBF-F418-AL** | 18 | 20 | 25 | 800 | 2500 | 3000 | 92 | 59.5 | 123 | M27×2 | M22×1.5 | 2.85 |
| CBF-F420-AL** | 20 | 20 | 25 | 600 | 2500 | 3000 | 63 | 60.5 | 125 | M27×2 | M22×1.5 | 3.05 |
| CBF-F425-AL** | 25 | 16 | 20 | 600 | 2500 | 3000 | 93 | 63.8 | 131.5 | M33×2 | M27×2 | 3.20 |
| CBF-F432-AL** | 32 | 16 | 20 | 600 | 2500 | 3000 | 93 | 67.5 | 139 | M33×2 | M27×2 | 3.50 |
| CBF-F440-AL** | 40 | 16 | 20 | 600 | 2500 | 3000 | 93 | 72 | 148 | M33×2 | M27×2 | 3.50 |
| CBF-F450-AL** | 50 | 16 | 20 | 600 | 2500 | 3000 | 93 | 72 | 148 | M33×2 | M27×2 | 3.90 |
Applications
Forklifts
Agricultural machinery
Loaders and tractors
Hydraulic power units
CBF-F4 pumps are typically packaged securely to prevent damage during transit. The packaging includes:
Protective Wrapping: To safeguard the pump from environmental damage.
Custom Crates: For larger, heavier pumps, ensuring safe handling.
Documentation: Includes installation, maintenance instructions, and warranty details.
Delivery time depends on the model, customizations, and location but typically ranges from 2 to 6 weeks from the order date.
What is a P50 / P51 hydraulic gear pump?
P50 and P51 are heavy-duty external gear pumps designed for reliable hydraulic power transmission in mobile and industrial equipment.
What applications are P50 / P51 gear pumps used for?
They are commonly used in construction machinery, agricultural equipment, forklifts, dump trucks, and hydraulic power units.
What is the operating pressure of P50 / P51 hydraulic pumps?
These pumps are designed for high-pressure performance, with operating pressures up to 3000 PSI (207 bar).
Are P50 / P51 gear pumps available in different displacements?
Yes, multiple displacement options are available to match different flow and performance requirements.
Can P50 / P51 pumps be supplied in tandem or multiple sections?
Yes, single, tandem, and multiple pump configurations are available for various hydraulic systems.
Are different shaft and mounting options available?
Yes, P50 / P51 pumps offer various shaft types, flange mounts, and port options for easy replacement.
Are P50 / P51 hydraulic gear pumps interchangeable with original models?
Compatible replacement models are available to match original specifications and performance.
Do you supply P50 / P51 hydraulic pump repair kits and spare parts?
Yes, repair kits, seal kits, and replacement parts are available for maintenance and overhaul.
CBF-F4 pumps are manufactured in compliance with international standards, ensuring high performance and reliability:
ISO 9001: Certified for quality management systems.
CE Certification: Ensures compliance with European safety, health, and environmental protection standards.
RoHS Compliance: Ensures the pump does not contain hazardous materials.
Factory Testing: Every pump is rigorously tested for performance, pressure, and leak integrity before shipping.
The pump's flow is adjusted by changing the angle of an internal swash plate. As the swash plate angle changes, the stroke length of the pistons varies, which in turn changes the volume of fluid displaced per rotation, allowing the flow rate to adapt to the system's needs.
Factory established in 2005;
With a great deal of production experience;
80+ employees become the professional team;
Constant updated ERP system ensure efficiency of work;
Sophisticated equipment ehanced the accuracy of products;
Professional salesmen provide the greast service;
With a large number of famous customers all over the world;
Great after-sales service;
With the long term cooperation with famous logistics and express company in China,provide the better goods service.
Small order/sample order,full payment in advance; Big orders send the first payment 30% before the production,and the balance before shippment.We'll show the photos of the products and packages before delivery.
Of course we can. Just send me your logo we can make it for you.
America(40.5%):USA, Canada, Argentina, Brazil
Europe(30.8%):Italy,Germany,England,Holland,Spain,Swiss,Finland,Russia,Poland.
Asia(23.5%):Korea,singapore,India,Turkey,Vietnam,Saudi Arabia,Syria, Israel,Lebanon.
Others(5.8%).
The Green hydraulic pump manufacturing facility is a specialized industrial plant that focuses on producing hydraulic pumps and related components. These factories are equipped with advanced machinery and technology to fabricate high-quality pumps designed for a wide range of applications, from heavy equipment and machinery to automotive and industrial systems.
The production process typically involves precision engineering, where raw materials like metals and alloys are processed into pump components such as gears, pistons, cylinders, and seals. These parts are then assembled into fully functional hydraulic pumps, which are tested for performance and quality control to ensure reliability, efficiency, and durability under various working conditions.
Green Hydraulic's manufacturing facilities for hydraulic pumps maintain stringent quality standards, often adhering to international certifications, to meet the expectations of customers in industries such as construction, agriculture, automotive, and manufacturing.
All hydraulic pumps produced by Green Hydraulic have undergone compliance testing, ensuring their quality and reliability.
To meet the diverse needs of different industries, the green hydraulic offer customization options, such as specialized seals, materials, and pump configurations. These facilities often work closely with engineering teams to develop tailored solutions for specific applications, from high-pressure systems to low-flow, high-efficiency pumps.
Each pump undergoes a rigorous quality control process, where pressure tests and performance assessments are conducted to ensure that the pumps meet the required standards for flow rate, pressure capacity, and durability.
